Fully Automatic KN95 Mask Making line
Automatic KN95 Mask Making line
The machine undergoes non-woven fabric welding, ear-loop welding, printing, half-folding, edge banding, rolling cutting and other integrated automatic folding production processes, which can make 3M 9001, 9002 and other folding masks. By using different raw materials, it can produce masks that meet different standards, such as FFP1, FFP2, N95, etc.
Working Process:
Automatic unwinding – nose bridge feeding – ultrasonic welding – logo printing – ear loop welding – folding forming – ultrasonic welding cutting – finished mask output
Device parameters:
- Adapt to product specifications:
Bond 3 ~ 6 layers of PP non-woven fabric and activated carbon filter material, and cut out the body of the folding mask. N95 dish masks are used for occupational respiratory protection, including certain microbial particles (such as viruses, bacteria, mold, Bacillus anthracis, Mycobacterium tuberculosis, etc.).
- Basic configuration parameters of the mask machine
Power supply: AC220V 50HZ, or as you require
Air source: 0.5 ~ 0.8MPA
Production efficiency: 40 ~ 50pcs / min
Production yield: ≥95%
Equipment size (mm): 9300 (L) * 1300 (W) * 1900 (H)
Features
- Automatic tension control of raw materials to ensure the balance of raw material tension.
- Photoelectric detection of raw materials to avoid mistakes and reduce waste.
- Frequency conversion control, the operating speed of the equipment can be adjusted as needed.
- High degree of automation, simple operation, only need to unwind and sort the finished product.
- The whole machine adopts sheet metal + aluminum alloy structure, beautiful and solid without rust
